CPD-25

2.5 TON ELECTRIC COUNTERBALANCE FORKLIFT

Reliable Seated Forklift For Warehouse And Factory Handling

The 2.5 ton electric counterbalance forklift is designed for pallet transport, warehouse loading, factory handling and daily indoor industrial material movement. With seated operation, stable mast structure and counterbalance design, it provides flexible pallet access and dependable lifting performance.

2500kg rated capacity for daily pallet handling

Counterbalance design without front support legs

Suitable for warehouse loading, pallet transfer and factory handling

MAIN FEATURES

2.5 Ton Electric Counterbalance Forklift For Daily Warehouse Work

With 2500kg rated capacity, 3000mm lift height and 48V/400Ah battery, this electric counterbalance forklift is built for pallet transport, loading operations and routine warehouse handling. It offers smooth operation and reliable indoor industrial performance.

Rated capacity: 2500 kg

Lift height: 3000 mm / Load center: 500 mm

48V / 400Ah battery with 13 km/h travel speed

STABLE MAST AND LIFTING

Strong Mast Structure For Pallet Stacking And Daily Handling

The reinforced mast and fork carriage provide stable lifting performance for pallet stacking and warehouse loading. Heavy-duty mast chains, reliable vertical lifting and mast tilt function help improve handling stability and daily productivity.

Lift height: 2500 mm

Mast lowered height: 1690 mm / Mast raised height: 3595 mm

Lifting speed laden: 300 mm/s / Mast tilt F/R: 6° / 8°

DAILY MATERIAL HANDLING

Built For Warehouse Storage, Pallet Transfer And Factory Loading

Designed for daily industrial use, this 2.5 ton forklift provides dependable handling for warehouse loading, pallet transfer and factory material movement. Solid tires, stable service weight and compact body structure help support frequent indoor operation.

Front tire: 6.50-10 solid

Rear tire: 16×6-8 solid

Ground clearance: 114 mm / Service weight: 3325 kg

CORE SPECIFICATIONS

Compact Dimensions For Efficient Warehouse Transport

The compact body and standard fork configuration help improve daily warehouse transport efficiency. With 2100mm overall length, 1100mm overall width and 1070×120×35mm fork size, it is suitable for common pallet handling and indoor warehouse loading tasks.

Overall length: 2100 mm / Overall width: 1100 mm

Fork size: 1070×120×35 mm

Fork spacing outside: 240–1000 mm / Overhead guard height: 2100 mm

POWER AND DRIVE SYSTEM

Efficient Power System For Everyday Industrial Operation

The forklift is equipped with a 48V/400Ah battery, 8kW AC travel motor and 10kW DC pump motor. The power system delivers smooth travel performance, strong hydraulic output and stable operation for productive warehouse material handling.

Battery: 48V / 400Ah

Travel motor: 8 kW AC / Pump motor: 10 kW DC

Travel speed: 13 km/h / Gradeability: 15% / Working pressure: 15 MPa

COUNTERBALANCE DESIGN

Flexible Pallet Access Without Front Support Legs

The counterbalance structure allows the forklift to access pallets without front support legs, making loading, unloading and pallet transfer more flexible. The balanced rear counterweight and compact turning parameters help improve movement efficiency in warehouse aisles.

Turning radius: 1930 mm

Min. right-angle aisle width: 1850 mm

Front overhang: 410 mm / Wheelbase: 1370 mm

TECHNICAL SPECIFICATIONS

2.5 Ton Electric Counterbalance Forklift Parameters

Main technical data for 2.5 ton electric counterbalance forklift. Suitable for pallet transport, warehouse loading, factory handling and daily indoor industrial material movement.

Category	Item	Unit	2.5 Ton Electric Counterbalance Forklift
Main Performance
Performance	Rated Capacity	kg	2500
Performance	Load Center	mm	500
Performance	Lift Height	mm	3000
Performance	Travel Speed	km/h	13
Performance	Gradeability	%	15
Performance	Working Pressure	MPa	15
Dimension
Dimension	Overall Length	mm	2100
Dimension	Overall Width	mm	1100
Dimension	Overhead Guard Height	mm	2100
Dimension	Fork Size	mm	1070×120×35
Dimension	Fork Spacing Outside	mm	240–1000
Dimension	Ground Clearance	mm	114
Mast
Mast	Mast Lowered Height	mm	1690
Mast	Mast Raised Height	mm	3595
Mast	Lifting Speed Laden	mm/s	300
Mast	Mast Tilt F/R	°	6 / 8
Turning And Body
Turning	Turning Radius	mm	1930
Turning	Min. Right-Angle Aisle Width	mm	1850
Turning	Front Overhang	mm	410
Turning	Wheelbase	mm	1370
Power And Tires
Power	Battery	V/Ah	48 / 400
Power	Travel Motor	kW	8 AC
Power	Pump Motor	kW	10 DC
Tire	Front Tire	–	6.50-10 Solid
Tire	Rear Tire	–	16×6-8 Solid
Weight	Service Weight	kg	3325

Need A Price For This 2.5 Ton Electric Counterbalance Forklift?

Tell us your required load capacity, lift height, pallet size, working aisle width and daily handling needs. We will recommend a suitable electric counterbalance forklift configuration for your warehouse operation.

Request a Quote

GET A FAST QUOTE

Looking For A 2.5 Ton Electric Counterbalance Forklift?

Please send your required capacity, lift height, pallet size, working aisle width and destination country. Our team will recommend the suitable model quickly.

✓ Required load capacity

✓ Required lift height

✓ Pallet size and fork spacing

✓ Working aisle width

✓ Destination country or port

Request A Quote

Please fill in your requirements below.
