Reliable Seated Forklift For Warehouse And Factory Handling
The 4 ton electric counterbalance forklift is designed for pallet transport, warehouse loading, truck loading and factory material handling. With a 4000kg rated capacity, seated operation and counterbalance design without front support legs, it provides flexible pallet access and stable daily industrial performance.
4 Ton Electric Counterbalance Forklift For Daily Handling
With 4000kg rated capacity, 3000mm lift height, 48V/400Ah battery and 13km/h travel speed, this forklift is built for dependable warehouse handling, pallet transfer and factory loading operations.
Strong Mast Structure For Stable Vertical Lifting
The reinforced mast and fork carriage are designed for stable lifting performance in warehouse and factory applications. Heavy-duty mast chains, strong carriage support and reliable vertical lifting help keep the forks level and secure during operation.
Built For Warehouse Loading, Factory Handling And Pallet Transfer
This 4 ton electric counterbalance forklift is suitable for warehouse storage, pallet transfer and factory loading. The stable body, solid tires and compact operating layout support frequent indoor industrial use.
Compact Dimensions For Efficient Warehouse Transport
The 4 ton electric counterbalance forklift uses a practical body layout for daily warehouse transport. With 2100mm overall length, 1100mm overall width and standard fork size, it is suitable for palletized goods handling in warehouses and factories.
Efficient Power System For Everyday Industrial Operation
The forklift is equipped with a 48V/400Ah battery, 11kW AC travel motor and 12kW DC pump motor. The power and hydraulic system provide stable travel, reliable lifting and smooth handling performance for daily industrial operation.
Flexible Pallet Access Without Front Support Legs
The counterbalance structure allows the forklift to access pallets directly without front support legs. This design improves flexibility for loading, unloading and pallet transfer in warehouse and factory environments.
4 Ton Electric Counterbalance Forklift Parameters
Main technical data for 4 ton electric counterbalance forklift. Suitable for warehouse loading, factory handling, pallet transfer and indoor industrial material movement.
| Category | Item | Unit | 4 Ton Electric Counterbalance Forklift |
|---|---|---|---|
| Main Performance | |||
| Performance | Rated Capacity | kg | 4000 |
| Performance | Load Center | mm | 500 |
| Performance | Lift Height | mm | 3000 |
| Performance | Travel Speed | km/h | 13 |
| Performance | Gradeability | % | 15 |
| Performance | Working Pressure | MPa | 15 |
| Dimension | |||
| Dimension | Overall Length | mm | 2100 |
| Dimension | Overall Width | mm | 1100 |
| Dimension | Overhead Guard Height | mm | 2100 |
| Dimension | Fork Size | mm | 1070×120×35 |
| Dimension | Fork Spacing Outside | mm | 240–1000 |
| Mast | |||
| Mast | Mast Lowered Height | mm | 1990 |
| Mast | Mast Raised Height | mm | 3990 |
| Mast | Lifting Speed Laden | mm/s | 300 |
| Mast | Mast Tilt F/R | ° | 6 / 8 |
| Turning And Body | |||
| Turning | Turning Radius | mm | 1930 |
| Turning | Min. Right-Angle Aisle Width | mm | 1850 |
| Turning | Front Overhang | mm | 410 |
| Turning | Wheelbase | mm | 1370 |
| Power And Tires | |||
| Power | Battery | V/Ah | 48 / 400 |
| Power | Travel Motor | kW | 11 AC |
| Power | Pump Motor | kW | 12 DC |
| Tire | Front Tire | – | 6.50-10 Solid |
| Tire | Rear Tire | – | 16×6-8 Solid |
| Weight | Service Weight | kg | 4650 |
